Yamaha S20 MID 3D placement machine SMT chip mounter machine S20 MID

Yamaha S20 MID 3D placement machine SMT chip mounter machine S20 MID

Yamaha S20 MID 3D placement machine SMT chip mounter machine S20 MID
Yamaha S20 MID 3D placement machine SMT chip mounter machine S20 MID Yamaha S20 MID 3D placement machine SMT chip mounter machine S20 MID Yamaha S20 MID 3D placement machine SMT chip mounter machine S20 MID Yamaha S20 MID 3D placement machine SMT chip mounter machine S20 MID Yamaha S20 MID 3D placement machine SMT chip mounter machine S20 MID Yamaha S20 MID 3D placement machine SMT chip mounter machine S20 MID

Large Image :  Yamaha S20 MID 3D placement machine SMT chip mounter machine S20 MID Get Best Price

Product Details:

Place of Origin: Japan
Brand Name: used chip mounter machine
Model Number: Yamaha S20 MID

Payment & Shipping Terms:

Price: $60,000.00 - $1,000,000.00/pieces
Packaging Details: SMT chip mounter machine
Supply Ability: 1000000 Piece/Pieces per Month SMT chip mounter machine
Detailed Product Description
Condition: New Weight (KG): 1000
Showroom Location: None Video Outgoing-inspection: Provided
Machinery Test Report: Provided Marketing Type: Hot Product 2019
Warranty Of Core Components: 1 Year Core Components: PLC
Warranty: 1 Year Product Name: SMT Chip Mounter Machine
Skype: Sensenhenhao Whatsapp/wechat: +8613424013606
Model Number:: YSM20 SMDCHIPMOUNTER Applicable Components:: Nts: 0402~5050
Usage:: SMD LED SMT Application:: SMT Assembly Production Line
Film Materials:: Privacy Material Power Supply:: AC220V 50Hz / AC110V
Lead Time: 7-30days Port: Shenzhen

Yamaha S20 MID 3D placement machine SMT chip mounter machine S20 MID

whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322



WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .

Also can support some original parts of machine repair.

SMT chip mounter machine S20 MID Features

PCB size: 1240mm x 510mm
The smallest component: 0201 (0.25x0.125mm) -120mm
Feida stations: 180
Mounting speed: 50000CPH
Product overview: YAMAHA/Yamaha S20 MID three-dimensional placement machine, PCB size: 1240mm x 510mm, minimum component: 0201 (0.25x0.125mm)-120mm, feeder stations: 180, placement speed: 50000CPH



SMT chip mounter machine main feature:

1. Realize the 3D MID (Molded Interconnect Device) process. The new frame and inclined structure can carry out three-dimensional assembly of uneven surfaces, inclined surfaces and curved surfaces, helping customers to achieve a leap from flat panel assembly to three-dimensional assembly, and reduce assembly costs.

2. It realizes the mixed function combination of spot solder paste/red glue/patch/plug-in functions, and can be easily switched. The non-contact dispensing head can spot solder paste on the cavity substrate to realize the three-dimensional assembly of uneven surfaces.

3. Perform optical inspection on the solder paste and glue and the mounted components. The newly developed color mark recognition camera can also perform stable optical inspection on the solder paste/glue shape and the patch effect through the new lighting system (to achieve AOI +SPI function)

4, 2 types of head structures are available, 6 placement heads, 6 rotation axis types, and 12 placement heads, 2 rotation axis types.

5. Super large substrate assembly capacity, the substrate can reach 1825mmx 635mm (optional) without segmentation, the ability to pass the board at one time is 1240mm x 510mm

6. Ultra-wide range of components, from ultra-small 0201 (0.25x0.125mm) chips to 120mm large components can be processed, and the mounting height reaches 35mm, making it easy to mount ultra-high components.

7. Super large feeding capacity. The 8mm feeding port of S20 reaches 4*45=180 types, the 8mm feeding port of S10 reaches 2*45=90 types, and the waffle tray feeding 36 types can realize non-stop refueling.

8. Motor material gun and refueling cart can be interchanged with M10/M20.

MID is the abbreviation of "Molded Interconnect Device" in English. The goal of 3D-MID technology is to combine electrical and mechanical functions in a single structural unit. The circuit is integrated on the shell to replace the traditional printed circuit board, thereby effectively reducing the weight and assembly space.
